Key Specifications

Interfaces

Ports

24 x 1000Base-T

Auto MDI/MDIX

Yes

CXP Port

120G CXP

Performance

Switching Capacity

48 Gbps

Maximum Forwarding Rate

35.712 Mpps

Store & Forward Switching

Yes

Packet Buffer Size

512 KBytes

MAC Address Table Size

16,000

Jumbo Frame Support

9,216 Bytes

Switch Intelligence

Unmanaged

Control Features

Flow Control

IEEE 802.3x Flow Control

Head-of-Line (HOL) Blocking Prevention

Yes

Energy Efficient Ethernet (EEE)

Yes

Power Saving

By Link Status and Cable Length

Power

Power Input

AC 100 ~ 240 V

Maximum Power Consumption

13.5 W

Standby Power Consumption

6.5 W

Maximum Heat Dissipation

46.035 BTU/h

Physical

Dimensions (W × D × H)

282.2 × 178 × 44.5 mm (11.11 × 7.01 × 1.75")

Weight

1.14 kg

Cooling

Fanless

Acoustic Noise

0 dB

Environmental

Operating Temperature

0°C to 40°C

Storage Temperature

-40°C to 70°C

Operating Humidity

10% to 90% RH

Storage Humidity

5% to 95% RH

Compliance

RoHS 6 Compliant

Yes

MTBF

247,291 Hours
