Key Specifications

Network Interface

Ethernet Ports

24 × 10/100/1000 BASE-T Ports

SFP Ports

2 × SFP Ports

Standards & Compliance

IEEE Standards

IEEE 802.3u (Fast Ethernet)
IEEE 802.3ab (Gigabit Ethernet)
IEEE 802.3z (Gigabit Fiber Ethernet)
IEEE 802.3af / 802.3at (PoE)
IEEE 802.3x (Flow Control / Full Duplex)
IEEE 802.3az (Energy Efficient Ethernet)

Standards Features

Auto MDI/MDI-X

Supported on all ports

Performance

Switching Fabric

52 Gbps

Transmission Method

Store-and-forward

Data Transfer Rates

100 Mbps / 1000 Mbps (Gigabit Ethernet)

PoE Capability

PoE Power Budget

250W (Max 30W per PoE port)

Power

Total Power

250W

Environmental Conditions

Operating Humidity

0% to 95% RH (Non-condensing)

Storage Humidity

0% to 95% RH (Non-condensing)

Physical Specifications

Dimensions

440 × 180 × 44 mm

Weight

3.0 kg

Protection

Lightning Protection

6KV
