Key Specifications

Product Type

Professional Digital Mixing Console

Internal Processing

32-bit Floating Point

ADC / DAC Performance

24-bit Depth | 114 dB Dynamic Range

SNR (Signal to Noise Ratio)

108 dB

Audio Performance

Frequency Response

20 Hz to 20 kHz (±1.5 dB)

Distortion (THD+N)

< 0.01% (@ 0 dBu, 1 kHz)

System Crosstalk

-88 dB (Input to Output) | -85 dB (Adjacent)

Max Output Levels

+20 dBu (Main / AUX / Control Room / HP)

Input Channel Strip

Mic Gain Range

0 dBu to 50 dBu (6.8 kΩ Impedance)

Line Gain Range

-15 dBu to +35 dBu (75 kΩ Impedance)

Phantom Power

+48V DC (±3V)

DSP & Signal Processing

4-Band Parametric EQ

21 Hz to 19.2 kHz (±24 dB per band)

Compressor

Ratio 1:1 to 10:1 | Threshold -30 to +20 dBu

Noise Gate

Threshold -84 to -20 dB | Attack 0.5ms

Physical Specifications

Output Impedance

240 Ω (All outputs)

Operating Temperature

0 to 40°C (32 to 104°F)
