Key Specifications

Aircraft

Takeoff Weight

< 249 g

Dimensions

Folded: 136×62×165 mm (L×W×H)
Unfolded: 233×280×79 mm (L×W×H)

Max Ascent Speed

5 m/s (Sport mode)
5 m/s (Normal mode)
2 m/s (Cine mode)

Max Descent Speed

5 m/s (Sport mode)
5 m/s (Normal mode)
1.5 m/s (Cine mode)

Max Horizontal Speed

12 m/s (Sport mode)
12 m/s (Tracking Status)
16 m/s with 4 m/s tailwind

Max Takeoff Altitude

3000 m

Max Flight Time

31 minutes

Max Hovering Time

28 minutes

Max Flight Distance

14 km

Max Wind Speed Resistance

10.7 m/s (Level 5)

Operating Temperature

-10° to 40° C (14° to 104° F)

Global Navigation Satellite System

GPS + Galileo + BeiDou

Hovering Accuracy Range

Vertical:
±0.1 m (with vision positioning)
±0.5 m (with satellite positioning)

Horizontal:
±0.3 m (with vision positioning)
±1.5 m (with satellite positioning)

Internal Storage

2 GB

Class

C0 (EU)

Camera

Image Sensor

1/1.3-inch image sensor

Lens

FOV: 82.1°
Format Equivalent: 24 mm
Aperture: f/1.7
Focus: 1 m to ∞

ISO Range

Video:
100-6400 (Normal)
100-1600 (D-Log M)

Photo:
12MP: 100-6400
48MP: 100-3200

Shutter Speed

12MP Photo: 1/16000-2 s
48MP Photo: 1/8000-2 s

Max Image Size

48MP Photo
8064×6048

Still Photography Modes

Single Shot: 12 MP and 48 MP
Burst Shooting: 3/5/7 frames
AEB: 3/5/7 frames at 2/3 EV step
Timed: 2/3/5/7/10/15/20/30/60 s

Photo Format

JPEG
DNG/RAW

Video Resolution

4K: 3840×2160@24/25/30/48/50/60/100fps
FHD: 1920×1080@24/25/30/48/50/60/100fps
2.7K Vertical: 1512×2688@24/25/30fps
FHD Vertical: 1080×1920@24/25/30fps

Video Format

MP4

Max Video Bitrate

150 Mbps

Supported File System

exFAT

Color Mode

Normal
D-Log M

Digital Zoom

4K: 3x
FHD: 4x
2.7K Vertical: 3x
FHD Vertical: 4x
12 MP Photo: 3x

Gimbal

Stabilization

3-axis mechanical gimbal (tilt, roll, pan)

Mechanical Range

Tilt Axis: -130° to +63°
Roll Axis: -47° to +47°
Pan: -30° to +30°

Controllable Range

Tilt Axis: -90° to +35°

Max Control Speed (Tilt)

100°/s

Angular Vibration Range

±0.01°

Sensing

Sensing Type

Downward visual sensor and infrared sensor
Forward 3D Infrared Sensing System

Forward Detection

Measurement Range: 0.3-8 m
FOV: Horizontal 60°, Vertical 60°

Downward Detection

Measurement Range: 0.3-8 m
Precise Hovering Range: 0.5-10 m
FOV: Horizontal 60°, Vertical 60°

Operating Environment

Surfaces with clear patterns, reflectivity above 20%, and lighting above 15 lux

Video Transmission

Video Transmission System

O4

Live View Quality

Up to 1080p/60fps

Operating Frequency

2.4000-2.4835 GHz
5.170-5.250 GHz
5.725-5.850 GHz

Max Transmission Distance

FCC: 13 km
CE: 8 km
SRRC: 8 km
MIC: 8 km

Max Download Speed

DJI RC-N3 / DJI RC 2: 10 MB/s
Wi-Fi 5: 30 MB/s

Lowest Latency

Approx. 120 ms

Antenna

4 antennas (2.4 GHz: 1T2R; 5.2/5.8 GHz: 2T2R)

Wi-Fi

Protocol

802.11a/b/g/n/ac

Operating Frequency

2.4000 GHz-2.4835 GHz
5.7250 GHz-5.850 GHz

Effective Operating Range

50 m

Bluetooth

Protocol

Bluetooth 5.0

Operating Frequency

2.4000-2.4835 GHz

Transmitter Power (EIRP)

< 10 dBm

Battery

Capacity

3110 mAh

Weight

Approx. 83.5 g

Nominal Voltage

7.16 V

Battery Type

Li-ion

Chemical System

LiNiMnCoO2

Energy

22.3 Wh

Charging Temperature

5° to 40° C (41° to 104° F)

Charging Time

Via Aircraft: Approx. 70 minutes
Battery Charging Hub (Single Battery): Approx. 45 minutes
Battery Charging Hub (Parallel Charging): Approx. 70 minutes

Battery Charging Hub

Input

5 V, 4.3 A
9 V, 4.3 A
12 V, 4.3 A
15 V, 4.3 A

Output (Power Accumulation)

Max 45 W

Output (Charging)

15 V, 2 A
12 V, 2 A
9 V, 3 A
5 V, 3 A

Rated Power

65 W

Charging Type

Supports Parallel Charging of Two Batteries

Compatibility

DJI Flip Intelligent Flight Battery

Charger

Recommended Charger

DJI 65W Portable Charger
USB Power Delivery chargers

Storage

Recommended microSD Cards

Kingston CANVAS Go! Plus
Lexar Professional 1066x

DJI RC-N3 Remote Controller

Max Operating Time

Without charging mobile device: 3.5 hours
While charging mobile device: 1.5 hours

Operating Temperature

-10° to 40° C (14° to 104° F)

Max Supported Mobile Device Size

180×86×10 mm (L×W×H)

App

Mobile Device App

DJI Fly

Required Operating System

iOS 13.0 or later
Android 7.0 or later
