Key Specifications

Aircraft

Takeoff Weight

151 g (without DJI Neo 2 Digital Transceiver)
160 g (with DJI Neo 2 Digital Transceiver)

Dimensions

147×171×41 mm (L×W×H, with propeller guards and without DJI Neo 2 Digital Transceiver)
167×171×54 mm (L×W×H, with propeller guards and DJI Neo 2 Digital Transceiver)

Max Ascent Speed

0.5 m/s (Cine mode)
3 m/s (Normal mode)
5 m/s (Sport Mode)

Max Descent Speed

0.5 m/s (Cine Mode)
3 m/s (Normal Mode)
3 m/s (Sport Mode)

Max Horizontal Speed

8 m/s (Normal Mode)
12 m/s (Sport Mode)
12 m/s (tracking status)

Max Takeoff Altitude

2000 m

Max Flight Time

Approx. 19 minutes (Approx. 17 minutes with propeller guards)
Each battery supports at least 20 palm takeoff and landing cycles

Max Hovering Time

Approx. 18 minutes (16.5 minutes with propeller guards)

Max Flight Distance

7 km

Max Wind Speed Resistance

10.7 m/s (Level 5)

Operating Temperature

-10° to 40° C (14° to 104° F)

Global Navigation Satellite System

GPS + Galileo + BeiDou

Hovering Accuracy Range

Vertical:
±0.1 m (with vision positioning)
±0.5 m (with satellite positioning)

Horizontal:
±0.3 m (with vision positioning)
±1.5 m (with satellite positioning)

Internal Storage

49 GB

Class

C0 (EU)

Camera

Image Sensor

1/2-inch CMOS Sensor

Lens

FOV: 119.8°
Format Equivalent: 16.5 mm
Aperture: f/2.2
Focus: 0.7 m to ∞

ISO Range

Photo:
100-3200 (Single Auto)
100-12800 (Burst Auto/Timed Auto)
100-12800 (Manual)

Video:
100-12800 (Auto)
100-12800 (Manual)

Shutter Speed

Video: 1/8000-1/30 s
Photo: 1/8000-1/10 s

Max Image Size

12 MP Photo
4000×3000 (4:3)
4000×2250 (16:9)

Still Photography Modes

Single Shot: 12 MP
Timed Shot: 12 MP, 2/3/5/7/10/15/20/30/60 s

Photo Format

JPEG

Video Resolution

Horizontal Shooting:
4K (4:3): 3840×2880@60/50/30fps
1080p (4:3): 1440×1080@60/50/30fps
4K (16:9): 3840×2160@100/60/50/30fps
1080p (16:9): 1920×1080@100/60/50/30fps

Vertical Shooting:
2.7K (9:16): 1512×2688@60/50/30fps

Video Format

MP4

Max Video Bitrate

80 Mbps

Supported File System

exFAT

Color Mode

Normal

EIS

Supports RockSteady stabilization and stabilization off mode

Gimbal

Stabilization

2-axis mechanical gimbal (tilt, roll)

Mechanical Range

Tilt: -125° to 105°
Roll: -43° to 43°

Controllable Range

Tilt: -90° to 70°

Max Control Speed (Tilt)

100°/s

Angular Vibration Range

±0.01°

Image Roll Correction

Supports correction of footage recorded on the drone

Sensing

Sensing Type

Omnidirectional monocular vision system with downward infrared sensing and forward-facing LiDAR

Forward Detection

Measurement Range: 0.5-10 m
Detection Range: 0.5-15 m
Effective Sensing Speed: ≤ 8 m/s

Backward Detection

Detection Range: 0.5-15 m
Effective Sensing Speed: ≤ 8 m/s

Lateral Detection

Detection Range: 0.5-15 m
Effective Sensing Speed: ≤ 8 m/s

Upward Detection

Detection Range: 0.5-15 m
Effective Sensing Speed: ≤ 3 m/s

Downward Detection

Detection Range: 0.5-15 m
Effective Sensing Speed: ≤ 3 m/s

Battery

Capacity

1606 mAh

Weight

46 g

Nominal Voltage

7.16 V

Max Charging Voltage

8.6 V

Battery Type

Li-ion

Energy

11.5 Wh

Charging Temperature

5° to 40° C (41° to 104° F)

Charging Time

Approx. 68 minutes for three batteries using Two-Way Charging Hub
Approx. 70 minutes charging directly through aircraft

Charger

Recommended Charger

DJI 65W Portable Charger
USB Power Delivery chargers

Battery Charging Hub

Input

5 V, max 5 A
9 V, max 5 A
12 V, max 5 A
15 V, max 4.33 A
20 V, max 3.25 A

Output (Charging)

5 V, 2 A

Charging Method

3 batteries charged simultaneously

Compatibility

DJI Neo 2 Intelligent Flight Battery

Bluetooth

Protocol

Bluetooth 5.2

Operating Frequency

2.400 GHz to 2.4835 GHz

Transmitter Power (EIRP)

< 10 dBm
