Key Specifications

Compatibility

MIDAS M-Series

Processor

A/D-D/A Conversion (Cirrus Logic A/D CS5368, D/A CS4385): 24-Bit at 44.1 / 48 kHz, 114 dB Dynamic Range
Networked I/O Latency (Stagebox In > Console Processing > Stagebox Out): 1.1 ms

Performance

Input/Output Characteristics
Frequency Response at 48 kHz Sample Rate, at Any Gain: 20 Hz to 20 kHz, 0 dB to -1 dB
Dynamic Range, Analog Mic In to Analog Out: 107 dB, 22 Hz to 22 kHz, Unweighted
A/D Dynamic Range, Mic Preamp to Converter: 109 dB, 22 Hz to 22 kHz, Unweighted
D/A Dynamic Range, Converter, and Output: 110 dB, 22 Hz to 22 kHz, Unweighted
Crosstalk Rejection at 1 kHz, Adjacent Channels: 100 dB

Output Characteristics
Output Impedance, XLR: 50 Ohms
Maximum Output Level, XLR: +21 dBu
Residual Noise Level, Unity Gain, XLR: < -86 dBu, 22 Hz to 22 kHz, Unweighted
Residual Noise Level, Muted, XLR: < -100 dBu, 22 Hz to 22 kHz, Unweighted

Inputs / Outputs

USB I/O

1 × USB-B Female Input

Audio I/O

32 × XLR 3-Pin Line/Mic Input
16 × XLR 3-Pin Line Output

Digital I/O

AES50 SuperMAC Networking:
48 or 44.1 kHz, 24-Bit PCM: 2 × 48 Channels, Bidirectional
AES50 SuperMAC Cable Length:
Cat 5e Shielded: Up to 328.1' / 100 m
ULTRANET Networking:
48 or 44.1 kHz, 22-Bit PCM: 1 × 16 Channels, Unidirectional
ULTRANET Cable Length:
Cat 5 Shielded: Up to 246.1' / 75 m
ADAT Output:
48 or 44.1 kHz, 24-Bit PCM: 2 × 8 Channels, Unidirectional
TOSLINK Optical Cable Length:
16.4' / 5 m, Typical
AES/EBU Output:
48 or 44.1 kHz, 24-Bit PCM: 2 × 2 Channels, Unidirectional
XLR:
110 Ohms Balanced, Cable Length: 16.4' / 5 m, Typical

Microphone Input

Preamplifiers:
Midas PRO Preamplifiers
Input Impedance, XLR:
10 Kilohms
Non Clip Maximum Input Level, XLR:
+23.5 dBu
THD + Noise, Unity Gain, 0 dBu Out:
< 0.01%, Unweighted
THD + Noise, +45 dB Gain, 0 dBu Out:
< 0.03%, Unweighted
Phantom Power:
Switchable per Input, 48 V
Equivalent Input Noise at +45 dB Gain, 150 Ohms Source:
< -126 dBu, 22 Hz to 22 kHz, Unweighted
CMRR at 1 kHz, Unity Gain:
> 70 dB Typical
CMRR at 1 kHz, +45 dB Gain:
> 90 dB Typical

Power

Power Source

AC Input (Included)

AC Input Power

100 to 240 VAC, 50 / 60 Hz

Power Consumption

55 W

Physical

Color

Gray

Environmental Resistance

No

Dimensions

19 × 9.5 × 5.4" / 48.3 × 24.1 × 13.7 cm

Weight

12.5 lb / 5.7 kg

Packaging Information

Package Weight

14.74 lb

Box Dimensions (L × W × H)

21.5 × 12.4 × 8.5"
