Key Specifications

I/O & Processing

• 64 mic/line inputs, 32 line outputs
• 128 Input Channels with full processing
• 64 Mix Outputs with full processing
• Configurable 64 bus architecture (group, FX, aux, matrix, mains)
• LR, LCR and up to 5.1 mains mode
• Multiple PFLs
• 16 RackExtra FX with dedicated stereo returns
• 24 DCAs
• AMM (Automatic Mic Mixer) up to 64 channels across 1, 2 or 4 zones
• Built-in signal generator and RTA
• New preamp design for extra transparency
• Unique Active PAD circuit for consistent performance with any source

Core & Performance

• XCVI 160 x 64 FPGA core
• 96kHz sample rate
• Variable bit-depth for ultimate precision and noise performance
• Virtually infinite mix headroom thanks to 96bit accumulator
• Class leading, ultra-low latency at 0.7ms

Connectivity & Expansion

• Connection hub
• gigaACE gigabit link to Surface
• 2x DX links for I/O expansion
• I/O Port 128 ch 96 kHz
• Dedicated ME-1 48kHz port
• 2x Network ports
• Wordclock BNC I/O
• Add up to 22 DX I/O expanders via DX Hub modules or DX Link cards

Physical

• Flush front panel with ultra quiet fan
• Reversible rack ears design
