Key Specifications

General

• Compatibility: Allen & Heath dLive / AHM / Avantis / SQ

System

• Sample Rate: 96 kHz ±20 PPM
• Latency: +8 Samples, DX32 to Mixrack or DX32 to Surface (DX Hop)
• System Latency: <0.6 ms (MixRack XLR in to XLR out, Input to Mix), +5 Samples, Surface to Mixrack (GigaACE Hop)

Inputs / Outputs

• Network I/O: 2 x EtherCON Connectors

Power

• Power Source: AC Input (Included)
• AC Input Power: 100 to 240 VAC, 50 / 60 Hz
• Power Consumption: 250 W (Maximum)

Environmental

• Operating Temperature: 32 to 95°F / 0 to 35°C

Physical

• Color: Black
• Cable Length: Not Specified by Manufacturer
• Dimensions: 17 x 11.4 x 7" / 43.2 x 29 x 17.8 cm
• Weight: 23 lb / 10.4 kg

Packaging Info

• Package Weight: 26.73 lb
• Box Dimensions (L x W x H): 23.4 x 16.7 x 12.8"
