SE ELECTRONICS DM1
SE ELECTRONICS DM1
|
Key Specifications |
|
|
In-Line Accessory Type |
Preamplifier |
|
Input / Output Level |
Input: Mic Level |
|
Number of Channels |
1 |
|
Gain |
+28 dB (1 kΩ Load) |
|
Circuit Type |
Class-A FET |
|
Controls |
No |
|
Connectivity |
|
|
Inputs / Outputs |
1x XLR 3-Pin Female Input |
|
Performance |
|
|
Frequency Response |
10 Hz to 120 kHz (-0.3 dB) |
|
Impedance |
135 Ohms |
|
Load Impedance |
1 kΩ (Minimum) |
|
Max Output Level |
+8.3 dBV (0.5% THD) |
|
Power |
|
|
Operating Voltage |
48 V (Phantom Power) |
|
Operating Current Consumption |
3.0 mA |
|
Physical |
|
|
Dimensions |
3.76 x 0.75" / 9.55 x 1.91 cm |
|
Weight |
2.8 oz / 79.9 g |
|
Packaging Info |
|
|
Package Weight |
0.235 lb |
|
Box Dimensions (LxWxH) |
6.3 x 1.25 x 1.25" |
