Key Specifications

Product Type

Professional Digital Mixing Console

Internal Processing

32-bit Floating Point

ADC / DAC Performance

24-bit bit depth | 114 dB Dynamic Range

SNR (Signal to Noise Ratio)

109 dB

Visual Interface

Main Display

10.1-inch LCD (1024 x 600)

Channel Displays

0.96-inch individual LCDs (128 x 64)

Audio Performance

Frequency Response

22 Hz to 22 kHz (±1.5 dBu)

Max Input / Output Level

+20 dBu (±0.5 dBu)

Distortion (THD+N)

< 0.03% (@ 0 dBu, 1 kHz)

DSP & Signal Processing

4-Band Parametric EQ

21 Hz to 19.2 kHz (±24 dBu range)

Compressor Ratio

1:1 to Limit (Infinite)

Noise Gate Threshold

-80 dBu to -30 dBu

Impedance & Temp

Input / Output Impedance

6.8 kΩ (Mic) | 120 Ω (All Outputs)

Operating Temp

0ºC to 40ºC (32ºF to 104ºF)
