Key Specifications

Amplifier Class

D

Output Power (RMS, All Channels Driven)

2 x 160 W @ 4 Ω
2 x 160 W @ 8 Ω
1 x 320 W @ 4 Ω (Bridge)
1 x 320 W @ 8 Ω (Bridge)

Output Power @ 70 V

1 x 320 W @ 70 V

Frequency Response (-3 dB)

20 Hz - 20 kHz

SNR (A-weighted)

93 dB

Distortion (THD+N) @ 1 kHz

< 0.01 %

Input / Output Section

Unbalanced Inputs

2x Stereo RCA, 1x 3.5mm Aux

Unbalanced Outputs

1x Stereo RCA Line Out

Network / Control

2x RJ45 Ethernet, 1x USB-B

Other I/O

2x Screw Terminal (Mute/Control)

Processing

DSP

Yes

EQ Filters

Parametric EQ

High-Pass Filter

Yes

Protections

Cooling

Forced Convection

General Protections

AC Fuse, DC Fault, Infrasonic, Short Circuit, Thermal

Power Requirements

Operating Voltage

90–240 V~ 50/60 Hz

Power Consumption (Max)

400 W

Physical Specifications

Display

OLED

Rack Mounting

1/2 19", 1U (optional rack mounting accessory required)

Dimensions (H × W × D)

43 x 213 x 302 mm / 1.7 x 8.4 x 11.9 inches

Weight

1.6 kg / 3.6 lbs

Shipping Information

Package Height

109 mm / 4.3 inches

Package Width

378 mm / 14.9 inches

Package Depth

419 mm / 16.5 inches

Package Weight

2.6 kg / 5.75 lbs
