Key Specifications

Amplifier Class

D

Number of Channels

4

Output Power (RMS, All Channels Driven)

4 x 500 W @ 4 Ω
4 x 500 W @ 8 Ω

Bridge / High Voltage Mode

2 x 1000 W @ 70 V / 100 V

Frequency Response (-3 dB)

20 Hz - 20 kHz

SNR (A-weighted)

> 93 dBA

Distortion (THD+N) @ 1 kHz

< 0.01 %

Input / Output Section

Analog Inputs

2x Stereo RCA, 2x Balanced Block (Mic/Line), 1x 3.5mm Aux

Analog Outputs

1x Stereo RCA Line Out

Digital / Network I/O

3x RJ45, 1x USB-B

Processing

DSP

Yes

EQ Filters

LF Boost, High-Pass Filter

Protections

Cooling

Forced Convection

General Protections

AC Fuse, DC Fault, RMS, Short Circuit, Thermal

Power Requirements

Operating Voltage

90–240 V~ 50/60 Hz

Power Consumption (Max)

800 W

Physical Specifications

Display

OLED

Dimensions (H × W × D)

96 x 430 x 360 mm / 3.8 x 16.9 x 14.2 inches

Weight

6.2 kg / 13.7 lbs
