Key Specifications

Amplifier Class

D

Output Power

2 x 80 W @ 4 Ω
2 x 80 W @ 8 Ω
1 x 160 W @ 4 Ω (Bridge)
1 x 160 W @ 8 Ω (Bridge)

Output Power @ 70 V

1 x 160 W @ 70 V

Frequency Response (-3 dB)

20 Hz - 20 kHz

Distortion (THD+N) @ 1 kHz

< 0.01 %

Input Section

Total Number of Inputs

5

Balanced Inputs

2

Unbalanced Inputs

3

Mono Inputs

2

Stereo Inputs

3

VOX

Yes

Line Inputs

3

Line Connectors

Jack, Picoflex, RCA

Mic + Line Inputs

1

Mic + Line Connectors

Euroblock

Paging Inputs

1

Paging Connectors

RJ45

Paging Command

Contact

General Purpose Inputs (GPI)

1

Output Section

Signal Output Number

1

Signal Output Connectors

RCA

Power Output Connectors

Euroblock

Processing

DSP

Yes

EQ Filters

Yes

FIR

Yes

Compressors

Yes

Tone Controls

Yes

High-Pass Filter

80 Hz - 200 Hz

Configuration and Control

Configuration

Front panel, PC Software

RCF Speaker Presets

Yes

System Integration Protocols

Proprietary, RDNet

Onboard Control

Yes

Protections

Cooling

Forced

Short Circuit Protection

Yes

Thermal Protection

Yes

DC Protection

Yes

Fuses

Yes

VHF Protection

Yes

Power Requirements

Operating Voltage

90–240 V~ 50/60 Hz

Power Consumption (Max)

200 W

Standard Compliance

Safety Agency

CE compliant, UL 62368-1

Physical Specifications

Cabinet / Case Material

Metal

Color

Black

Rack Mounting

1/2 19", 1U (optional rack accessory required)

Dimensions (H × W × D)

44 x 213 x 314 mm / 1.73 x 8.39 x 12.36 inches

Weight

1.7 kg / 3.75 lbs

Shipping Information

Package Height

106 mm / 4.17 inches

Package Width

360 mm / 14.17 inches

Package Depth

381 mm / 15 inches

Package Weight

2.7 kg / 5.95 lbs
