Key Specifications

Frequency Response (-10 dB)

80 Hz - 20000 Hz

Max SPL @ 1m / 4m

101 dB / 89 dB

Coverage Angle

210°

System Sensitivity

88 dB (1W @ 4m: 76 dB)

Power Section

Power Handling

20 W (RMS), 80 W (Peak)

Constant Voltage Transformer

100 V

Power Selection (Taps)

20 W, 10 W, 5 W, 2.5 W

Transducers

1 x 5.0" Full Range

Standard Compliance

IP Protection Grade

IP 65

Safety Certifications

CE compliant, EN54-24 certified

CPR Number

0068-CPR-058/2014

Physical Specifications

Material

Flameproof ABS cabinet, Steel grille

Hardware

Wall mount metal plate

Color

White - RAL 9016

Dimensions (H x W x D)

183 x 176 x 261 mm / 7.2 x 6.93 x 10.28 inches

Weight

2.61 kg / 5.75 lbs

Shipping Information

Package Dimensions

230 x 400 x 380 mm / 9.06 x 15.75 x 14.96 inches

Package Weight

3.54 kg / 7.8 lbs
