Key Specifications

Image Sensor

1/2.8" Progressive Scan CMOS

Maximum Resolution

1920 × 1080 (Full HD)

Minimum Illumination

Color: 0.002 Lux @ F1.4, B/W: 0 Lux with IR

Day & Night

IR Cut Filter

WDR

120 dB

Lens

Lens Type

Fixed Focal Lens

Available Focal Lengths

2.8 mm, 4 mm, 6 mm

Lens Mount

M12

Aperture

F1.4

Field of View

Up to 107° Horizontal, 57° Vertical, 129° Diagonal

IR Illumination

Supplement Light Type

Infrared (IR)

IR Range

Up to 40 m

Smart IR

Yes

IR Wavelength

850 nm

Video

Video Compression

H.265, H.265+, H.264, H.264+, MJPEG

Maximum Frame Rate

30 fps @ 1920 × 1080

Video Bit Rate

32 Kbps to 8 Mbps

Bit Rate Control

CBR / VBR

ROI

1 Fixed Region for Main and Sub Stream

Audio

Built-In Microphone

Yes (-U Model)

Audio Compression

G.711, G.722.1, G.726, MP2L2, PCM, MP3, AAC-LC

Noise Filtering

Environment Noise Filtering

Network

Ethernet Interface

1 × RJ45 10/100 Mbps

Protocols

TCP/IP, HTTP, HTTPS, RTSP, RTP, FTP, DHCP, DNS, IPv4, IPv6, SSL/TLS and more

Simultaneous Live View

Up to 6 Channels

Supported Platforms

iVMS-4200, Hik-Connect, Hik-Central

Storage

microSD Card Slot, Supports up to 256 GB

Smart Features

Motion Detection

Human and Vehicle Classification

Smart Events

Line Crossing, Intrusion, Region Entrance/Exit, Scene Change Detection

Face Capture

Yes

Privacy Mask

Yes

Power & Environmental

Power Input

12 VDC ±25% or PoE (802.3af Class 3)

Power Consumption

Max. 7 W

Operating Temperature

-30°C to 60°C (-22°F to 140°F)

Weather Protection

IP67 Rated

Material

Metal

Physical Specifications

Dimensions

Ø74.4 × 179.2 mm (Ø2.9 × 7.1")

Weight

Approx. 500 g (1.1 lb)

Package Weight

Approx. 750 g (1.7 lb)
