Key Specifications

Image Sensor

1/3" Progressive Scan CMOS

Maximum Resolution

2688 × 1520

Minimum Illumination

Color: 0.001 Lux @ F1.0 (AGC ON)
B/W: 0 Lux with IR

Day/Night Mode

IR Cut Filter

Lens Options

2.8 mm or 4 mm Fixed Lens

Aperture

F1.0

Video Performance

Main Stream

Up to 2688 × 1520 @ 30 fps

Video Compression

H.265, H.264, H.265+, H.264+, MJPEG

Bit Rate

32 Kbps to 8 Mbps

Wide Dynamic Range

120 dB WDR

Image Enhancement

BLC, HLC, 3D DNR

Signal-to-Noise Ratio

≥ 52 dB

Illumination

Supplement Light

Infrared (IR)

IR Range

Up to 40 m

Smart IR

Yes

IR Wavelength

850 nm

Audio

Built-In Microphone

Yes (-U Model)

Audio Compression

G.711, G.722.1, G.726, MP2L2, PCM, MP3, AAC-LC

Noise Filtering

Environmental Noise Filtering

Network & Storage

Network Interface

1 × RJ45 10/100 Mbps Ethernet Port

Protocols

TCP/IP, HTTP, HTTPS, FTP, RTSP, RTP, DHCP, DNS, IPv4, IPv6, SNMP, SSL/TLS and more

On-Board Storage

microSD/microSDHC/microSDXC up to 512 GB

Simultaneous Live View

Up to 6 Channels

Supported Clients

iVMS-4200, Hik-Connect, Hik-Central

Smart Features

Face Capture

Yes

Perimeter Protection

Line Crossing, Intrusion, Region Entrance, Region Exit

Target Classification

Human and Vehicle Detection

Motion Detection

Yes

Privacy Masks

4 Programmable Polygon Masks

Power & Environmental

Power Input

12 VDC ±25% or PoE (IEEE 802.3af)

Power Consumption

Max. 7 W

Operating Temperature

-30°C to 60°C (-22°F to 140°F)

Weather Protection

IP67 Rated

Construction

Metal Front Cover, Body, and Bracket

Physical Specifications

Dimensions

Ø74.4 × 179.2 mm (Ø2.9 × 7.1")

Weight

Approx. 525 g (1.2 lb)

Package Weight

Approx. 750 g (1.7 lb)
