Key Specifications

Image Sensor

1/2.8" Progressive Scan CMOS

Maximum Resolution

1920 × 1080

Minimum Illumination

0.0005 Lux @ F1.0 (Color, AGC ON)
0 Lux with White Light

Lens Options

2.8 mm or 4 mm Fixed Lens

Aperture

F1.0

Lens Mount

M12

Video Performance

Main Stream Resolution

Up to 1920 × 1080 @ 30 fps

Video Compression

H.265, H.264, H.265+, H.264+, MJPEG

Video Bit Rate

32 Kbps to 8 Mbps

Bit Rate Control

CBR / VBR

Wide Dynamic Range

120 dB WDR

Image Enhancement

BLC, HLC, 3D DNR

Signal-to-Noise Ratio

≥ 52 dB

Illumination

Supplement Light Type

White Light

Supplement Light Range

Up to 30 m

Smart Supplement Light

Yes

Audio

Built-In Microphone

Yes (-U Model)

Audio Compression

G.711, G.722.1, G.726, MP2L2, PCM, MP3, AAC-LC

Audio Sampling Rates

8 / 16 / 32 / 44.1 / 48 kHz

Noise Filtering

Environmental Noise Filtering

Network & Storage

Network Interface

1 × RJ45 10/100 Mbps Ethernet Port

Protocols

TCP/IP, HTTP, HTTPS, FTP, DHCP, DNS, RTSP, RTP, IPv4, IPv6, SSL/TLS, SNMP and more

On-Board Storage

microSD / microSDHC / microSDXC up to 512 GB

Simultaneous Live View

Up to 6 Channels

Supported Clients

iVMS-4200, Hik-Connect, Hik-Central

Smart Features

Face Capture

Yes

Smart Detection

Line Crossing, Intrusion, Region Entrance, Region Exit

Target Classification

Human and Vehicle Detection

Motion Detection

Yes

Scene Change Detection

Yes

Power & Environmental

Power Input

12 VDC ±25% or PoE (IEEE 802.3af)

Power Consumption

Max. 7 W

Operating Temperature

-30°C to 60°C (-22°F to 140°F)

Storage Temperature

-30°C to 60°C (-22°F to 140°F)

Protection Rating

IP67

Physical Specifications

Dimensions

Ø138.3 × 115.4 mm (Ø5.4 × 4.5")

Weight

Approx. 770 g (1.7 lb)

Package Weight

Approx. 980 g (2.2 lb)
