Key Specifications

Image Sensor

1/1.8" Progressive Scan CMOS

Maximum Resolution

2688 × 1520

Minimum Illumination

0.0005 Lux @ F1.0 (Color), 0 Lux with Light

Shutter Speed

1/3 s to 1/100,000 s

Lens Options

2.8 mm or 4 mm Fixed Focal Lens

Aperture

F1.0

Lens Mount

M16

Field of View

2.8 mm Lens

111.1° Horizontal / 57.6° Vertical / 138.5° Diagonal

4 mm Lens

95.2° Horizontal / 48.3° Vertical / 117.4° Diagonal

Illumination

Supplement Light

IR and White Light

Light Range

Up to 30 m

Smart Supplement Light

Yes

IR Wavelength

850 nm

Video

Video Compression

H.265, H.264, H.265+, H.264+, MJPEG

Frame Rate

Up to 30 fps at 2688 × 1520

Video Bit Rate

32 Kbps to 8 Mbps

Bit Rate Control

CBR / VBR

Scalable Video Coding

H.264 and H.265 Encoding

Audio

Built-In Microphone

Yes (-U Model)

Audio Compression

G.711, G.722.1, G.726, MP2L2, PCM, MP3, AAC-LC

Noise Filtering

Environment Noise Filtering

Network

Ethernet Port

1 × RJ45 10/100 Mbps

Protocols

TCP/IP, HTTPS, RTSP, RTP, FTP, DHCP, DNS, IPv4/IPv6, SSL/TLS, SNMP, WebSocket and more

Simultaneous Live View

Up to 6 Channels

ONVIF Support

Profile S, Profile G, Profile T

Maximum Users

32 Users

Storage

Memory Card Slot

microSD / microSDHC / microSDXC up to 512 GB

Network Storage

NAS (NFS, SMB/CIFS), ANR

Image Features

Wide Dynamic Range

130 dB WDR

Image Enhancement

BLC, HLC, 3D DNR

Signal-to-Noise Ratio

≥ 52 dB

Privacy Masks

4 Programmable Polygon Masks

Smart Features

Face Capture

Yes

Perimeter Protection

Line Crossing, Intrusion, Region Entrance & Exit Detection

Target Classification

Human and Vehicle Detection

Power & Environmental

Power Input

12 VDC ±25% or PoE (IEEE 802.3af Class 3)

Power Consumption

Max. 5 W (DC), Max. 6 W (PoE)

Operating Temperature

-30°C to 60°C (-22°F to 140°F)

Protection Rating

IP67 Weatherproof

Physical

Material

Metal Cover and Main Body

Dimensions

Ø138.3 × 115.4 mm (Ø5.4 × 4.5")

Weight

Approx. 770 g (1.7 lb)
