Key Specifications

Camera

Image Sensor

1/1.8" Progressive Scan CMOS

Max. Resolution

2560 × 1440

Min. Illumination

Color: 0.0005 Lux @ (F1.2, AGC ON)

B/W: 0.0001 Lux @ (F1.2, AGC ON)

0 lux with light

Shutter Speed

1/1 s to 1/30000 s

Day & Night

IR cut filter

Zoom

12× optical, 16× digital

Focal Length

6.7 mm to 80.4 mm

Field of View (FOV)

H: 51.5° to 7.9°

V: 30.3° to 4.4°

D: 57.9° to 9.0°

Focus

Auto / Semi-auto / Manual

Aperture

Max. F1.2

Zoom Speed

Approx. 5.8 s

Illuminator

Hybrid (IR + White Light)

White Light: up to 100 m

IR: up to 150 m

PTZ

Pan Range

360°

Tilt Range

-15° to 90° (auto flip)

Pan Speed

Up to 160°/s (configurable), preset 240°/s

Tilt Speed

Up to 120°/s (configurable), preset 200°/s

Presets

300

Video

Main Stream

2560 × 1440 / 1920 × 1080 / 1280 × 960 / 1280 × 720

25–30 fps

Sub Stream

704 × 576 / 640 × 480 / 352 × 288 (25–30 fps)

Compression

H.265 / H.264 / MJPEG

Bit Rate

32 kbps to 16384 kbps

Audio

Audio Compression

G.711 / G.722.1 / G.726 / MP2L2 / PCM / AAC-LC

Network

Protocols

IPv4/IPv6, HTTP, HTTPS, FTP, SMTP, SNMP, NTP, RTSP, RTP, TCP/IP, UDP, DHCP, PPPoE, DNS

Users

Up to 32

Interface

Ethernet

RJ45 10/100 Mbps

Storage

MicroSD up to 512 GB

Alarm I/O

2 inputs / 1 output

General

Power

24 VAC / Hi-PoE

Power Consumption

Max. 42 W

Operating Temp

-30 °C to 65 °C

Material

ADC12

Protection

IP66 / IK10 / 6000 V surge protection

Weight

Approx. 5.5 kg
