Key Specifications

Camera

Image Sensor

[Bullet channel] 1/2.8" Progressive Scan CMOS

[PTZ channel] 1/2.8" Progressive Scan CMOS

Max. Resolution

[Bullet channel] 1920 × 1080

[PTZ channel] 1920 × 1080

Min. Illumination

[Bullet channel]: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with light

[PTZ channel]: Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0.001 Lux @ (F1.6, AGC ON), 0 Lux with IR

Shutter Speed

1 s to 1/30,000 s

Day & Night

ICR

Zoom

[PTZ channel] 15× optical, 16× digital

Focal Length

[Bullet channel] 2.8 mm

[PTZ channel] 5 to 75 mm (15× optical)

Field of View (FOV)

[Bullet channel] H: 106.1° / V: 56.8° / D: 126.5°

[PTZ channel] H: 54.8° to 4° / V: 31.4° to 2.3° / D: 62.2° to 4.6°

Focus

Auto, Manual, Semi-auto

Aperture

[Bullet channel] F1.0

[PTZ channel] F1.6

Zoom Speed

[PTZ channel] approx. 2.3 s

Illuminator

[Bullet channel] White Light (up to 30 m)

[PTZ channel] IR (up to 100 m)

PTZ Range

Pan: 360°

Tilt: -15° to 90° (auto flip)

Pan/Tilt Speed

0.1° to 80°/s (configurable), preset speed 80°/s

Presets

300

Video

Video Compression

H.265 / H.264 / MJPEG

Video Bit Rate

32 kbps to 16384 kbps

ROI

8 fixed regions per stream

Audio

Audio Compression

G.711 / G.722 / G.726 / AAC-LC

Network

Protocols

IPv4/IPv6, HTTP, HTTPS, TCP/IP, UDP, RTP, RTSP, FTP, SMTP, DHCP, DNS, NTP, SNMP, UPnP, QoS

Simultaneous Live View

20

User/Host

32

Interface

Ethernet

RJ45, 10/100 Mbps self-adaptive port

Storage

Micro SD up to 256 GB

Alarm I/O

1 input / 1 output

General

Power

DC 12V / PoE+

Power Consumption

Max. 24 W

Operating Temperature

-30°C to 65°C

Material

ADC12

Protection

IP66, 6000V lightning protection

Weight

Approx. 2.4 kg
