Key Specifications

Camera

Image Sensor

[Bullet channel]: 1/2.5" Progressive Scan CMOS

[PTZ channel]: 1/2.8" Progressive Scan CMOS

Max. Resolution

[Bullet channel]: 3632 × 1632

[PTZ channel]: 1920 × 1080

Min. Illumination

[Bullet channel]: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with light

[PTZ channel]: 0.005 Lux (Color), 0.001 Lux (B/W), 0 Lux with IR

Shutter Speed

1 s to 1/30,000 s

Day & Night

ICR

Zoom

PTZ channel: 25× optical, 16× digital

Lens

Bullet: 2.8 mm

PTZ: 4.8 to 120 mm (25× optical)

FOV

Bullet: 180° horizontal / 80° vertical

PTZ: 54.8° to 2.8° horizontal

PTZ Movement Range

Pan: 360°

Tilt: -15° to 90° (auto flip)

Video

Main Stream

Bullet: up to 3632 × 1632 @ 25/30 fps

PTZ: up to 1920 × 1080 @ 25/30 fps

Sub Stream

Bullet: up to 1200 × 536

PTZ: up to 704 × 576 / 704 × 480

Video Compression

H.265, H.264, MJPEG

Video Bit Rate

32 kbps to 16384 kbps

Audio

Audio Compression

G.711, G.722.1, G.726, AAC-LC, MP3, PCM

Audio Interface

1 input (line in), 1 output (line out)

Network

Protocols

IPv4/IPv6, HTTP, HTTPS, TCP/IP, DHCP, DNS, RTSP, SNMP, NTP, ONVIF

Remote Users

Up to 32 users

Interface

Ethernet

RJ45 10/100 Mbps

Storage

Micro SD up to 256 GB

General

Power

12VDC, PoE+

Power Consumption

Max 24 W

Operating Temperature

-30°C to 65°C

Protection

IP66, surge protection, lightning protection

Weight

Approx. 2.4 kg
