Key Specifications

Camera

Image Sensor

[Bullet channel] 1/1.8" Progressive Scan CMOS

[PTZ channel] 1/1.8" Progressive Scan CMOS

Max. Resolution

[Bullet channel] 2560 × 1440

[PTZ channel] 2560 × 1440

Min. Illumination

[Bullet channel]: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with light

[PTZ channel]: Color: 0.005 Lux @ (F1.5, AGC ON), B/W: 0.001 Lux @ (F1.5, AGC ON), 0 Lux with IR

Shutter Speed

1 s to 1/30,000 s

Day & Night

ICR

Zoom

[PTZ channel] 32× optical, 16× digital

Focal Length

[Bullet channel] 4 mm

[PTZ channel] 5.9 to 188.8 mm (32× optical)

Field of View (FOV)

[Bullet channel] H: 88.7° / V: 44.7°

[PTZ channel] H: 60.2° to 2.3° / V: 35.2° to 1.3°

Focus

Auto / Manual / Semi-auto

Aperture

[Bullet channel] F1.0

[PTZ channel] F1.5

Zoom Speed

[PTZ channel] approx. 5.6 s

Illuminator

[Bullet channel] White Light (up to 30 m)

[PTZ channel] IR (up to 200 m)

PTZ Range

Pan: 360°

Tilt: -15° to 90° (auto flip)

Pan/Tilt Speed

Pan: up to 160°/s (configurable), preset 240°/s

Tilt: up to 120°/s (configurable), preset 200°/s

Presets

300

Video

Video Compression

H.265 / H.264 / MJPEG

Video Bit Rate

32 kbps to 16384 kbps

ROI

8 fixed regions per stream (main, sub, third)

Audio

Audio Compression

G.711 / G.722 / G.726 / MP2L2 / PCM

Network

Protocols

IPv4/IPv6, HTTP, HTTPS, TCP/IP, UDP, RTP, RTSP, DHCP, DNS, NTP, SMTP, FTP, SNMP, UPnP, QoS

Simultaneous Live View

20

User/Host

32

Interface

Ethernet

RJ45, 10/100 Mbps self-adaptive port

Storage

Micro SD up to 256 GB

Alarm I/O

2 inputs / 1 output

General

Power

24 VAC / Hi-PoE

Power Consumption

Max. 42 W

Operating Temperature

-30°C to 65°C

Material

ADC12

Protection

IP66, IK10, 6000V lightning protection

Weight

Approx. 6 kg
