DS-96128NI-M16
DS-96128NI-M16
HIKVISION
Price for Inquiry
UNIT: PIECE/S
Product Code: SKU:HIKV-DS96128N-CHN-3525
Key Features
HIKVISION DS-96128NI-M16
HIKVISION DS-96128NI-M16
|
Key Specifications |
|
|
IP Video Input |
128-ch |
|
Incoming Bandwidth |
400 Mbps |
|
Outgoing Bandwidth |
400 Mbps |
|
Video Output |
|
|
HDMI 1 Output |
8K (7680 × 4320) / 30Hz 4K (3840 × 2160) / 60Hz 4K (3840 × 2160) / 30Hz 2K (2560 × 1440) / 60Hz 1920 × 1080 / 60Hz 1600 × 1200 / 60Hz 1280 × 1024 / 60Hz 1280 × 720 / 60Hz 1024 × 768 / 60Hz |
|
HDMI 2 Output |
4K (3840 × 2160) / 60Hz 4K (3840 × 2160) / 30Hz 2K (2560 × 1440) / 60Hz 1920 × 1080 / 60Hz 1600 × 1200 / 60Hz 1280 × 1024 / 60Hz 1280 × 720 / 60Hz 1024 × 768 / 60Hz When HDMI 1 is set to 8K, HDMI 2 max resolution is 1080p |
|
VGA Output |
|
|
VGA 1 Output |
1920 × 1080 / 60Hz 1280 × 1024 / 60Hz 1280 × 720 / 60Hz 1024 × 768 / 60Hz |
|
VGA 2 Output |
1920 × 1080 / 60Hz 1280 × 1024 / 60Hz 1280 × 720 / 60Hz 1024 × 768 / 60Hz |
|
Video Output Mode |
HDMI 1 + VGA 1 (Main Output, simultaneous) HDMI 2 + VGA 2 (Auxiliary Output, simultaneous) |
|
CVBS Output |
1-ch BNC (PAL: 704 × 576 / NTSC: 704 × 480) |
|
Audio |
|
|
Audio Input |
1-ch RCA |
|
Audio Output |
2-ch RCA |
|
Two-Way Audio |
1-ch RCA |
|
Audio Compression |
G.711ulaw / G.711alaw / G.722 / G.726 AAC / MP2L2 / PCM |
|
Decoding |
|
|
Decoding Format |
H.265+ / H.265 / H.264+ / H.264 |
|
Recording Resolution |
Up to 32 MP supported 32 MP / 24 MP / 12 MP / 8 MP / 7 MP / 6 MP / 5 MP / 4 MP / 3 MP / 1080p / etc. |
|
Synchronous Playback |
16-ch |
|
Decoding Capability |
2-ch @ 32 MP (30 fps) 2-ch @ 24 MP (30 fps) 4-ch @ 16 MP (30 fps) 8-ch @ 8 MP (30 fps) 16-ch @ 4 MP (30 fps) 32-ch @ 2 MP (30 fps) |
|
Network |
|
|
Network Protocol |
TCP/IP, DHCP, IPv4/IPv6, DNS, DDNS, NTP, RTSP HTTP/HTTPS, SNMP, NFS, iSCSI, UPnP™, ONVIF |
|
Network Interface |
2 × RJ-45 10/100/1000 Mbps |
|
Camera Access Protocol |
ONVIF (2.5), RTSP |
|
Storage / Interface |
|
|
RAID |
RAID 0 / 1 / 5 / 6 / 10 |
|
SATA |
16 SATA interfaces (hot-plug) |
|
eSATA |
1 interface |
|
Alarm I/O |
16 / 9 |
|
USB |
Front: 2 × USB 2.0 Rear: 2 × USB 3.0 |
|
General |
|
|
Power Supply |
100–240 VAC, 50/60 Hz |
|
Power Consumption |
≤ 50 W (without HDD) |
|
Operating Temperature |
-10 °C to 55 °C |
|
Operating Humidity |
10%–90% |
|
Dimensions |
445 × 496 × 150 mm (3U chassis) |
|
Weight |
≤ 12.5 kg (without HDD) |
|
Certification |
CE, FCC |
HIKVISION DS-96128NI-M16 Accessories
- No accessories available.
