Key Specifications

Active or Passive

Active

System Type

Floor Monitor

Configuration

2-way

System Continuous Power

250 W

System Peak Power

500 W

Max SPL @ 1m

130 dB

Freq Range (-10 dB)

50 Hz - 20 KHz

Freq Response (+/-3 dB)

55 Hz - 18 KHz

Bluetooth

No

IP Certification

None

Driver Brand

Wharfedale Pro

LF Driver Size

15"

LF Voice Coil Size

2.5"

LF Rated Impedance

4 Ω

LF Power (RE:AES2-2012)

350 W

HF Driver Type

Compression Driver

HF Voice Coil Size

1.75"

HF Diaphragm Material

Titanium

HF Exit Size

1"

HF Power (RE:AES2-2012)

40 W

HF Rated Impedance

8 Ω

HF Nominal Coverage (H x V)

90° x 60°

Preset Library

No

Input Connector

2 × XLR & 2 × 1/4″ (Line/MIC)

Enclosure Material

MDF

Grille Material and Finish

Steel Black

Finish

Black Paint

Handles

2

Deployment

Ground

Pole Mount

None

Brackets Included

No

Rigging

No

Sensitivity 2.83v / 1m

n/a dB

System Rated Impedance

n/a

Recommended HPF = BW 18 dB/OCT.

50 Hz

Transformer (T)

No

Transformer Taps (70 V)

No

Transformer Taps (100 V)

No

Input Connectors (T)

No

Amplifier design

Class D

EQ Type

7-band EQ

Active Loudspeaker Input Impedance

Balanced: 20 K

Link Connector

Pin XLR

Input Sensitivity

775 mv

Max Input Level

6 v

Line Output

XLR (Balanced Out)

Main Power

220-240 V 50/60 Hz

Power Supply

SMPS

Included Accessory

User Manual, AC Cable

Unpacked - Height (mm)

520

Unpacked - Width Front (mm)

449

Unpacked - Width Rear (mm)

449

Unpacked - Depth (mm)

640

Packed - Height (mm)

485

Packed - Width Front (mm)

676

Packed - Width Rear (mm)

676

Packed - Depth (mm)

541

Weight - Nett (kg)

23.5

Weight - Gross (kg)

27.2
