Key Specifications

Active or Passive

Active

System Type

Subwoofer

Configuration

Bass-reflex

System Continuous Power

600 W

System Peak Power

1200 W

Max SPL @ 1m

132 dB (Half Space)

Freq Range (-10 dB)

30 Hz - 150 Hz

Freq Response (+/-3 dB)

35 Hz - 150 Hz

Bi-amp Mode Switch

No

Bluetooth

No

IP Certification

None

Driver Brand

Wharfedale Pro

LF Driver Size

18"

LF Voice Coil Size

2.5"

LF Rated Impedance

4 Ω

LF Power (RE:AES2-2012)

500 W

Preset Library

No

Input Connector

XLR & 1/4″ (Line/MIC)

Enclosure Material

MDF

Grille Material and Finish

Steel Black

Finish

Black Paint

Handles

2

Deployment

Ground

Pole Mount

35 mm

Brackets Included

No

Rigging

No

Sensitivity 2.83v / 1m

n/a dB

System Rated Impedance

n/a

Recommended HPF = BW 18 dB/OCT.

30 Hz

Transformer (T)

No

Transformer Taps (70 V)

No

Transformer Taps (100 V)

No

Input Connectors (T)

No

Amplifier design

Class D

Active Loudspeaker Input Impedance

Balanced: 20 K

Link Connector

2 × pin XLR

Input Sensitivity

775 mv

Max Input Level

6 v

Line Output

XLR THRU / HPF (Out)

Main Power

220-240 V 50/60 Hz

Power Supply

SMPS

Included Accessory

User Manual, AC Cable

Unpacked - Height (mm)

650

Unpacked - Width Front (mm)

528

Unpacked - Width Rear (mm)

528

Unpacked - Depth (mm)

639

Packed - Height (mm)

740

Packed - Width Front (mm)

725

Packed - Width Rear (mm)

725

Packed - Depth (mm)

614

Weight - Nett (kg)

38.3

Weight - Gross (kg)

44.2
