Key Specifications

Audio Performance

Frequency Response (-3 dB)

20 Hz - 22 kHz

Crosstalk

< -100 dB

Distortion (THD+N) @ 1 kHz Nominal Power

< 0.001%

Dynamic Range

> 110 dB

Common Mode Rejection Ratio (50 Hz to 10 kHz)

> 100 dB

Digital Audio Performance

Resolution

40-Bit

Sampling Rate

48 kHz

A/D - D/A Converters

24-Bit

Propagation Delay

3 ms

Input Section

Total Number of Inputs

17

Balanced Inputs

17

Mono Inputs

16

Mic + Line Inputs

16

Mic + Line Phantom Power

21 VDC - 44 VDC

Digital Inputs

1

Output Section

Signal Output Number

16

Processing

DSP

Yes

EQ Filters

Yes

Delay

Yes

Tone Controls

Yes

High-Pass Filter

20 Hz - 20 kHz

Crossover

20 Hz - 20 kHz

Controls

Number of Programs / Presets

70

Protections

Cooling

Convection / Forced

Fuses

Yes

Power Requirement

Operating Voltage

90-240 V~ 50/60 Hz

Power Consumption (Max)

20 W

Standard Compliance

Safety Agency

CE Compliant

Physical Specifications

Cabinet / Case Material

Metal

Color

Black

Rack Mounting

19", 1U

Size / Weight

Height

44 mm / 1.73"

Width

483 mm / 19.02"

Depth

229 mm / 9.02"

Weight

3.31 kg / 7.3 lb
