Key Specifications

Speaker Configuration

10 × 2-Way Speaker Column with Subwoofer

Number of Input Channels

2 (2 × Mono)

Amplifier Power Rating

Speakers: 600 W
Subwoofer: 500 W

Amplifier Class

Class-D

Speakers

Enclosure Type

Speaker: Sealed
Subwoofer: Bass-Reflex

HF Driver

10 × 1.5" / 3.8 cm Dome

Subwoofer Driver

1 × 12" / 30.5 cm Woofer

Signal Processing

Crossover

240 Hz

Input Pad

No

EQ

No

Semi-Parametric EQ

No

Effects

3 × Preset (Factory)

Filters

No

Dynamic Processing

Limiter

Performance

Frequency Response

37 Hz to 20 kHz ±10 dB

Maximum SPL

125 dB SPL (Peak)

Coverage Angle

170° H × 30° V

I/O Impedance

XLR Mic Input: 3 kΩ
XLR Line Input: 20 kΩ
1/4" Line Input: 10 kΩ
XLR Line Output: 75 Ω

Protections

Overcurrent, Signal Limiter, Thermal

Connectivity

Audio I/O

1 × Combo XLR-1/4" TRS Mic/Line Input
1 × Combo XLR-1/4" TRS Line Input
1 × XLR Female Link Input
1 × XLR Male Link Output

USB I/O

No

Network I/O

No

Power

AC Input Power

110–120 VAC, 60 Hz / 220–240 VAC, 50 / 60 Hz

Power Consumption

25 W (Idle), 91 W (1/8 Power)

AC Power I/O

1 × IEC Input

Physical

Transport Options

Subwoofer: 1 × Handle (Top)

Construction Material

ABS

Environmental Resistance

No

Certifications

WEEE

Dimensions

System: 78.7 × 16.5 × 13.1" / 200 × 41.8 × 33.4 cm

Weight

50.7 lb / 23 kg

Packaging Info

Package Weight

63.7 lb

Box Dimensions (L × W × H)

29.5 × 24 × 17"
