Key Specifications

Active/Passive

Passive

Number of Included Speakers

1

Speaker Configuration

2-Way

Power Handling

125 W RMS
250 W Program
500 W Peak

Constant Voltage / Transformer Taps

70 V / 100 V

Impedance

8 Ohms

HF Driver

1x Asymmetrical Horn Compression Driver

LF Driver

1x 8" / 203.2 mm Woofer

Frequency Range

45 Hz to 20 kHz (-10 dB)

Color

White

Speaker

Active/Passive

Passive

Number of Included Speakers

1

Speaker Configuration

2-Way

Power Handling

125 W RMS
250 W Program
500 W Peak

Recommended Amplifier Power

250 W RMS

Constant Voltage / Transformer Taps

70 V / 100 V

Impedance

8 Ohms

Drivers

HF Driver

1x Asymmetrical Horn Compression Driver

HF Voice Coil

1.3" / 33.02 mm

LF Driver

1x 8" / 203.2 mm

LF Voice Coil

1.5" / 38.1 mm

Performance

Frequency Range

45 Hz to 20 kHz (-10 dB)

Frequency Response

50 Hz to 18 kHz (±3 dB)

Maximum SPL

114 dB (Continuous)
120 dB (Peak)

Sensitivity

93 dB SPL

Coverage Angle

180° H x 75° V

Crossover

1 kHz

Connectivity

Inputs/Outputs

1x Block Speaker Input (Locking)

Physical

Certifications

UL

Color

White

Mounting

1x Ceiling Tile

Cutout Depth

9.3" / 236.2 mm

Cutout Size

13.6 x 13.6" / 345.4 x 345.4 mm

Dimensions

15.4 x 15.4 x 9.8" / 391.16 x 391.16 x 248.92 mm

Weight

22.2 lb / 10.1 kg (with Grille)

Packaging Info

Package Weight

30.65 lb

Box Dimensions (LxWxH)

17.3 x 17.2 x 13.01"
