Key  Specifications

System Type

12” 2 Way Full Range

Low Frequency (LF)

12” Woofer (2” Voice Coil Size)

High Frequency (HF)

1.5” Titanium Dome Tweeter

Frequency Response

45 Hz – 20 kHz

Amplifier Power

450 W MAX

Impedance

4 Ω

Input Gain

Line: +20 dBu
Mic: +40 dB

Input Connector

Line: XLR, RCA & 1/4" PL
Mic: 1/4" PL & XLR

Output Connector

Line: XLR & 1/4" PL Link Out
Speaker: Speakon (to passive speaker)

Total Harmonic Distortion (THD)

Less than 0.1%

Signal Indicator

Limit, Clip

Crossover Frequency

3 kHz

AC Input

220V 50–60Hz

Sensitivity

98 dB

Dimensions (H × W × D)

58 × 33 × 29 cm

Net Weight

12.5 kg
