Key Specifications

System Type

15” Active Speaker System

Low Frequency (LF)

15” Woofer (2” Voice Coil Size)

High Frequency (HF)

1.5” Titanium Dome Tweeter

Frequency Response

40 Hz – 20 kHz

Power

800 W

Impedance

4 Ω

Amplifier Power

500 W Class D

Input Gain

Line: +20 dBu / Mic: +40 dB

Input Connector

Line (XLR, RCA & PL), Mic (PL & XLR)

Output Connector

Line (XLR & PL link out), Speaker (Speakon to passive speaker)

THD

Less than 0.1%

Signal Indicator

Limit, Clip

Crossover Frequency

3 kHz

AC Input

220V 50-60Hz

Sensitivity

99 dB

Dimensions (H × W × D)

67 × 34.5 × 39 cm

Net Weight

14.5 kg
