Key Specifications

Portable PA System

• Amplifier Power Rating: 1x 1500 W Peak
• Impedance: 4 Ohms

Speakers

• Enclosure Type: Bass-Reflex
• Subwoofer Driver: 1x 18" / 45.7 cm
• Subwoofer Voice Coil: 3" / 7.6 cm
• Magnet: Ferrite

Signal Processing

• Crossover: 80 Hz, 100 Hz, 120 Hz
• Filters: No

Performance

• Frequency Response: 40 Hz to 120 Hz -3 dB
• Frequency Range: 31 Hz to 150 Hz -10 dB
• Maximum SPL: 131 dB
• Gain Range: 0 dB to +36 dB
• I/O Impedance: Input: 50 Kilohms (Unbalanced), 100 Kilohms (Balanced)

Connectivity

• Audio I/O: 2x Combo XLR-1/4" 3-Pin Female Balanced/Unbalanced Line Input, 2x XLR 3-Pin Male Balanced Line Output
• Wireless Connectivity: Bluetooth

Power

• AC Input Power: 100 to 120 VAC, 50 / 60 Hz

Physical

• Transport Options: 1x Handle (Each Side)
• Mounting: 1 x M20 Pole Socket (Top)
• Cooling: Convection
• Construction Material: Metal Grille, Plywood
• Dimensions: 26.5 x 24 x 25.1" / 674 x 609 x 637 mm
• Weight: 78.26 lb / 35.5 kg

Packaging Info

• Package Weight: 92.3 lb
• Box Dimensions (L x W x H): 29.5 x 29 x 28"
