Key Specifications

Monitor Type & Configuration

Active Subwoofer

Total Power Output

170 W RMS

Subwoofer Driver

1 x 10" / 25.4 cm Composite Cone

Audio I/O

2 x XLR 3-Pin Balanced Line Inputs
2 x 1/4" TRS Balanced Line Inputs
1 x Stereo 2RCA Unbalanced Line Input
2 x XLR 3-Pin Balanced Line Outputs
2 x 1/4" TRS Balanced Line Outputs
1 x XLR 3-Pin Balanced Sub Output

Digital Audio I/O

No

Wireless

No

Number of Included Monitors

Single Monitor

Enclosure

Bass-Reflex / Ported, Shielded

Drivers & Amplifiers

Drivers

1 x 10" / 25.4 cm Composite Cone

Amplifier

Subwoofer: 170 W RMS Class-AB

Performance

Frequency Response

20 Hz to 200 Hz

Maximum SPL

113 dB

Signal Processing

EQ

No

Filters

Low-Pass at 50 Hz
High-Pass at 130 Hz

Crossover Frequency

80 Hz

Phase Adjustment

0° / 180° Phase Inversion

Connectivity

USB

No

Mobile App Compatible

No

Power

AC Input Power

100 to 120 VAC, 50 / 60 Hz
220 to 240 VAC, 50 / 60 Hz

Power Consumption

230 W

Physical

Color

Black

Monitor Orientation

Vertical

Dimensions (W x H x D)

12.6 x 15.8 x 16" / 32 x 40.1 x 40.6 cm

Weight

37.0 lb / 16.8 kg

Packaging Info

Package Weight

43 lb

Box Dimensions (L x W x H)

21.6 x 19.9 x 17.9"
