Key Specifications

Channels

6

Load per Channel

0.2 A Minimum, 10 A Maximum

Frequency

50 / 60 Hz

Operating Voltage

120 to 240 VAC

Maximum Power Consumption

3 × 20 A

Inputs

Power Supply Input

3-Phase Connector, Internal Terminal Block / PG Cable Screw Joint, Optional CEE Connector

Analog Input

0 to +10 V via 8-Pin DIN

Digital Input

DMX512 via 5-Pin XLR

Outputs

Digital Output

DMX512 via 5-Pin XLR

Load Output

Internal Terminal Block / PG Cable Screw Joint, Optional Harting Connector

Fuses & Protection

Load Protection per Channel

10 A Cable Protection Switch (Type C)

Control Section Fuse

2 × T 100 mA H / 250 V

EU Voltage Fuse

1 × T 160 mA H / 250 V (220–230 V)

UL Voltage Fuse

2 × T 160 mA H / 250 V
1 × T 315 mA H / 250 V (120 V)

Physical Specifications

Dimensions (H × W × D)

3.3 × 19 × 15.9" / 84.3 × 482.6 × 403.8 mm

Weight

21.6 lb / 9.8 kg
