EVOX 12
EVOX 12
RCF
UNIT: PIECE/S
Product Code: SKU:RCF-EVOX12-CHN-333
Key Features
RCF EVOX 12
RCF EVOX 12
|
Key Specifications |
|
|
Frequency Response |
40 Hz – 20,000 Hz |
|
Maximum SPL @ 1 m |
130 dB |
|
Horizontal Coverage Angle |
90° |
|
Vertical Coverage Angle |
30° |
|
Transducers |
|
|
Fullrange Drivers |
8 × 4.0" drivers, 1.0" voice coil |
|
Woofer |
1 × 15" woofer, 3.0" voice coil |
|
Input / Output Section |
|
|
Input Signal |
Balanced / Unbalanced |
|
Input Connectors |
XLR, Jack |
|
Output Connectors |
XLR |
|
Input Sensitivity |
-2 dBu / +4 dBu |
|
Processor Section |
|
|
Crossover Frequency |
180 Hz |
|
Protections |
Thermal, RMS |
|
Limiter |
Soft Limiter |
|
Controls |
Volume, EQ |
|
Power Section |
|
|
Total Power |
1400 W Peak / 700 W RMS |
|
High Frequencies |
400 W Peak / 200 W RMS |
|
Low Frequencies |
1000 W Peak / 500 W RMS |
|
Cooling |
Convection |
|
Connections & Compliance |
|
|
Power Connection |
VDE |
|
CE Marking |
Yes |
|
Physical Specifications |
|
|
Cabinet Material |
Baltic Birch Plywood |
|
Color |
Black |
|
Height |
2200 mm / 86.61" |
|
Width |
410 mm / 16.14" |
|
Depth |
560 mm / 22.05" |
|
Weight |
36.4 kg / 80.25 lbs |
|
Packaging Information |
|
|
Package Weight |
43.89 kg / 96.76 lbs |
|
Product Dimensions |
9 × 17 × 17 inches |
|
What’s in the Box |
|
|
• Power Cord |
|
RCF EVOX 12 Accessories
- No accessories available.
