Key Specifications

Speaker Type

PA Speaker

Configuration

Active 2-Way

Amplifier & Power

Total Power Capacity

1400 W Peak / 700 W RMS

Low Frequency (LF)

1000 W Peak / 500 W RMS

High Frequency (HF)

400 W Peak / 200 W RMS

Amplifier Class

Class-D

Drivers

Full-Range Drivers

8 × 2" / 5.1 cm

HF Voice Coil

1" / 2.5 cm

LF Driver

1 × 12" / 30.5 cm Woofer

LF Voice Coil

2.5" / 6.4 cm

Performance

Frequency Response

40 Hz to 20 kHz

Maximum SPL

128 dB

Coverage Angle

120° H × 30° V

Input Sensitivity

+4 dBu / -2 dBu

Gain Range

0 to 45 dB

Total Harmonic Distortion / Noise

0.004%

Protections

RMS, Thermal

I/O Impedance

Mic Input

3 kΩ

Line Input

11 kΩ

Hi-Z Input

1 MΩ

Output

150 Ω

Signal Processing

Crossover Frequency

220 Hz

High-Pass Filter

20 Hz to 1 kHz

Dynamic Processing

Soft Limiter

Maximum Sampling Rate

48 kHz / 24-Bit

Connectivity

Audio I/O

1 × 1/4" TRS Footswitch Input
4 × Combo XLR-1/4" TRS Inputs
1 × XLR 3-Pin Input
1 × XLR 3-Pin Output
2 × 1/4" TS Inputs
1 × Stereo 2RCA Input
1 × speakON NL2 Input
1 × speakON NL2 Output
1 × 1/4" TRS Aux Output

USB I/O

1 × USB-B

Physical Specifications

Color

Black

Construction Material

Polypropylene Cabinet, Metal Grille

Certifications

CE

Dimensions (H × W × D)

24.5 × 15.7 × 18.1" / 62.3 × 40 × 46 cm

Weight

53.8 lb / 24.4 kg

Packaging Information

Package Weight

64.65 lb

Box Dimensions (L × W × H)

27 × 23 × 18"
