Key Specifications

Active or Passive

Passive

System Type

Subwoofer

Configuration

Bass-reflex

System Continuous Power

400 W

System Programme Power

800 W

System Peak Power

1600 W

Max SPL @ 1m

131 dB (Half Space)

Freq Range (-10 dB)

35 Hz - 250 Hz

Freq Response (+/-3 dB)

40 Hz - 250 Hz

Bluetooth

No

IP Certification

None

Driver Brand

Wharfedale Pro

LF Driver Size

15"

LF Voice Coil Size

2.5"

LF Rated Impedance

4 Ω

LF Power (RE:AES2-2012)

400 W

Preset Library

Yes

Input Connector

2 × 4 Pole Speaker Connector / 2 × 6.3mm Jacks

Enclosure Material

Particle Board

Grille Material and Finish

Steel Black

Finish

Black Carpet

Handles

2

Deployment

Ground

Pole Mount

35 mm

Brackets Included

No

Rigging

No

Sensitivity 2.83v / 1m

99 dB

System Rated Impedance

4 Ω

Crossover Frequency

150 Hz

Recommended HPF = BW 18 dB/OCT.

35 Hz

Transformer (T)

No

Included Accessory

User Manual

Unpacked - Height (mm)

591

Unpacked - Width Front (mm)

460

Unpacked - Width Rear (mm)

460

Unpacked - Depth (mm)

510

Packed - Height (mm)

656

Packed - Width Front (mm)

556

Packed - Width Rear (mm)

556

Packed - Depth (mm)

506

Weight - Nett (kg)

28.06

Weight - Gross (kg)

31.06
