Key Specifications

Active or Passive

Passive

System Type

Subwoofer

Configuration

Bass-reflex

System Continuous Power

600 W

System Programme Power

1200 W

System Peak Power

2400 W

Max SPL @ 1m

134 dB (Half Space)

Freq Range (-10 dB)

30 Hz - 250 Hz

Freq Response (+/-3 dB)

35 Hz - 250 Hz

Bluetooth

No

IP Certification

None

Driver Brand

Wharfedale Pro

LF Driver Size

18"

LF Voice Coil Size

3"

LF Rated Impedance

4 Ω

LF Power (RE:AES2-2012)

600 W

Preset Library

Yes

Input Connector

2 × 4 Pole Speaker Connector / 2 × 6.3mm Jacks

Enclosure Material

Particle Board

Grille Material and Finish

Steel Black

Finish

Black Carpet

Handles

2

Deployment

Ground

Pole Mount

35 mm

Brackets Included

No

Rigging

No

Sensitivity 2.83v / 1m

100 dB

System Rated Impedance

4 Ω

Crossover Frequency

150 Hz

Recommended HPF = BW 18 dB/OCT.

30 Hz

Transformer (T)

No

Included Accessory

User Manual

Unpacked - Height (mm)

650

Unpacked - Width Front (mm)

522

Unpacked - Width Rear (mm)

522

Unpacked - Depth (mm)

610

Packed - Height (mm)

715

Packed - Width Front (mm)

656

Packed - Width Rear (mm)

656

Packed - Depth (mm)

568

Weight - Nett (kg)

39.3

Weight - Gross (kg)

42.6
