Key Specifications

Active or Passive

Passive

System Type

Full-Range

Configuration

Quasi 3-way

System Continuous Power

700 W

System Programme Power

1400 W

System Peak Power

2800 W

Max SPL @ 1m

135 dB

Freq Range (-10 dB)

35 Hz - 20 kHz

Freq Response (+/-3 dB)

40 Hz - 20 kHz

Bluetooth

No

IP Certification

None

Driver Brand

Wharfedale Pro

LF Driver Size

2 × 15"

LF Voice Coil Size

2.5"

LF Rated Impedance

8 Ω

LF Power (RE:AES2-2012)

2 × 350 W

HF Driver Type

Compression Driver

HF Voice Coil Size

1.75"

HF Diaphragm Material

Titanium

HF Exit Size

1"

HF Power (RE:AES2-2012)

40 W

HF Rated Impedance

8 Ω

HF Nominal Coverage (H x V)

90° x 60°

Preset Library

Yes

Input Connector

2 × 4 Pole Speaker Connector / 2 × 6.3mm Jacks

Waveguide Type

Elliptical

Enclosure Material

Particle Board

Grille Material and Finish

Steel Black

Finish

Black Carpet

Handles

2

Deployment

Ground

Pole Mount

None

Brackets Included

No

Rigging

No

Sensitivity 2.83v / 1m

100 dB

System Rated Impedance

4 Ω

Crossover Frequency

2.3 kHz

Recommended HPF = BW 18 dB/OCT.

35 Hz

Transformer (T)

No

Included Accessory

User Manual

Unpacked - Height (mm)

1058

Unpacked - Width Front (mm)

502

Unpacked - Width Rear (mm)

330

Unpacked - Depth (mm)

467

Packed - Height (mm)

1123

Packed - Width Front (mm)

564

Packed - Width Rear (mm)

362

Packed - Depth (mm)

496

Weight - Nett (kg)

41.28

Weight - Gross (kg)

46.06
