Key Specifications

System Type

2 Way Bass Reflex

Low Frequency (LF)

12” Woofer (3” Voice Coil)

High Frequency (HF)

2 × 1” exit Tweeters (1.7” Voice Coil)

Frequency Response

50 Hz – 20 kHz

Amplifier Power

700 W + 100 W Class D Amplifier

Maximum SPL

126 dB continuous

Coverage

110° (H) × 15° (V)

Input Connector

Line (XLR Female Jack)

Output Connector

Line (XLR Male Loop Through)

THD

Less than 0.5%

LED Indicators

Power, Signal, Clip

Crossover Frequency

1.5 kHz

AC Input

220 V, 50–60 Hz

Dimensions (H × W × D)

347 × 540 × 432 mm

Net Weight

20.8 kg

Gross Weight

70 kg (2 pcs in one flight case)

Packaging Dimensions (H × W × D)

970 × 640 × 490 mm
