WHARFEDALE EZ-12A
WHARFEDALE EZ-12A
|
Key Specifications |
|
|
Active or Passive |
Active |
|
System Type |
Full-Range |
|
Configuration |
2-way |
|
System Continuous Power |
50 W |
|
System Peak Power |
100 W |
|
Max SPL @ 1m |
115 dB |
|
Freq Range (-10 dB) |
65 Hz – 18 KHz |
|
Freq Response (+/-3 dB) |
70 Hz – 18 KHz |
|
Bi-amp Mode Switch |
No |
|
Bluetooth |
Yes |
|
IP Certification |
None |
|
Driver Brand |
Wharfedale Pro |
|
LF Driver Size |
12" |
|
LF Voice Coil Size |
1.5" |
|
LF Rated Impedance |
4 Ω |
|
LF Power (RE:AES2-2012) |
100 W |
|
HF Driver Type |
Compression Driver |
|
HF Voice Coil Size |
1" |
|
HF Diaphragm Material |
Resin Film |
|
HF Exit Size |
1" |
|
HF Power (RE:AES2-2012) |
15 W |
|
HF Rated Impedance |
8 Ω |
|
HF Nominal Coverage (H x V) |
90° x 50° |
|
Preset Library |
No |
|
Input Connector |
XLR and 1/4” Jack, L/R RCA Connector |
|
Waveguide Type |
Square |
|
Enclosure Material |
Polypropylene |
|
Grille Material and Finish |
Steel Black |
|
Finish |
Black Polypropylene |
|
Handles |
2 |
|
Deployment |
Pole, Ground |
|
Pole Mount |
35 mm With Lock Screw |
|
Brackets Included |
No |
|
Rigging |
No |
|
Sensitivity 2.83v / 1m |
n/a dB |
|
System Rated Impedance |
n/a |
|
Crossover Frequency |
2.6 KHZ |
|
Recommended HPF |
BW 18 dB/OCT. 65 Hz |
|
Transformer (T) |
No |
|
Amplifier design |
Class D |
|
Clip Limiter |
No |
|
EQ Type |
5-Band Graphic EQ |
|
Line output |
L/R RCA Connector |
|
Main Power |
Up to 5 hours (6 hours charge time) |
|
Battery Specs |
12 v, 7.5 Ah lead acid battery |
|
Included Accessories |
Two Wireless Mics, IR Remote Control, User Manual, AC Cable |
|
Unpacked Dimensions (mm) |
640 (H) x 420 (W) x 350 (D) |
|
Weight (Nett / Gross) |
11 kg / 14.8 kg |
