Key Specifications

Active or Passive

Active

System Type

Full-Range

Configuration

2-way

System Continuous Power

70 W

System Peak Power

140 W

Max SPL @ 1m

118 dB

Freq Range (-10 dB)

55 Hz – 18 KHz

Freq Response (+/-3 dB)

65 Hz – 18 KHz

Bi-amp Mode Switch

No

Bluetooth

Yes

IP Certification

None

Driver Brand

Wharfedale Pro

LF Driver Size

15"

LF Voice Coil Size

1.5"

LF Rated Impedance

4 Ω

LF Power (RE:AES2-2012)

120 W

HF Driver Type

Compression Driver

HF Voice Coil Size

1"

HF Diaphragm Material

Resin Film

HF Exit Size

1"

HF Power (RE:AES2-2012)

15 W

HF Rated Impedance

8 Ω

HF Nominal Coverage (H x V)

90° x 50°

Preset Library

No

Input Connector

XLR and 1/4” Jack, L/R RCA Connector

Waveguide Type

Square

Enclosure Material

Polypropylene

Grille Material and Finish

Steel Black

Finish

Black Polypropylene

Handles

2

Deployment

Pole, Ground

Pole Mount

35 mm With Lock Screw

Brackets Included

No

Rigging

No

Sensitivity 2.83v / 1m

n/a dB

System Rated Impedance

n/a

Crossover Frequency

2.6 KHZ

Recommended HPF

BW 18 dB/OCT. 55 Hz

Transformer (T)

No

Amplifier design

Class D

Clip Limiter

No

EQ Type

5-Band Graphic EQ

Line output

L/R RCA Connector

Main Power

Up to 5 hours (6 hours charge time)

Battery Specs

12 v, 7.5 Ah lead acid battery

Included Accessories

Two Wireless Mics, IR Remote Control, User Manual, AC Cable

Unpacked Dimensions (mm)

740 (H) x 490 (W) x 400 (D)

Weight (Nett / Gross)

12.7 kg / 17.2 kg
