Key Specifications

RF Carrier Frequency Range

470MHZ-960MHZ

Oscillation Mode

PLL frequency synthesis

Transmission Power

13.5dBm

Carrier Error

0.005%

Harmonic Radiation

-32dBm

Modulation Mode

FSK

Nominal/Maximum Frequency Deviation

± 65KHz

Frequency Setting

Infrared synchronization

Audio Inputs & Controls

Maximum Input Level

250mV

Input Impedance

Mic 2.2KΩ , Line 4.7 KΩ

Input Gain Adjustment Range

4-level adjustable setting, every 3dB step

Power & Battery Life

Power Supply Mode

AA 1.5Vx2

Normal Working Current

AA battery power supply: 120mA

Battery Life

>8 hours

Dimensions & Weight

Boundary Dimension (mm)

198 x 52.5 x 28

Weight (without battery)

About 50g
