Key Specifications

Carrier Frequency Range

470MHz-960MHz

Frequency Stability

0.005%

Receiving Mode

Dual channel, superheterodyne true diversity receiving

Effective Working Distance (Ideal Environment)

≥ 60m

Image Suppression

45dBm

RF Sensitivity

S/N ≥ 45dB when 10dBu is input

Frequency Synchronization Mode

Infrared SYNC

Silence Adjustment

Built-in setting parameters

Audio Performance

Audio Companding

DSP digital audio companding

Audio Sampling Rate

48KHz

Audio Frequency Response

50Hz - 18000Hz ± 3dB

Dynamic Range

92 dB

Signal to Noise Ratio (A-weighted)

105 dB

Total Harmonic Distortion

≤ 0.8%, @ 1KHz

Audio Output & Controls

Maximum Output Level

LINE: 0.5Vpp

Output Level Adjustment Range

6-level adjustable, attenuating adjustment, step by step every 3dB

Power & Operating Conditions

Power Supply Mode

DC 12V/1A

Normal Working Current

DC 12V: 250mA

Operating Temperature Range

- 10 ℃~+50 ℃

Dimensions & Weight

Dimensions (mm)

410 (L) x 212 (D) x 43 (H)

Weight (without battery)

About 1.76kg
