Key Specifications

Enclosure Type

Bass Reflex (Full-Range)

Power Capacity (8 Ω)

120 W (Program) / 60 W (Continuous)

Speaker Component

12 cm (5") Cone-type

Sensitivity

90 dB (1 W, 1 m)

Tapping & Impedance

100 V Line

30W / 10W / 3W / 1W

70 V Line

30W / 15W / 5W / 1.5W / 0.5W

Low Impedance

8 Ω or 16 Ω Selectable

Performance & Physical

Frequency Response

70 Hz – 20,000 Hz (-10 dB)

Mounting Hole

ø200 mm (7.87")

Input Terminal

Removable Locking Connector (Screw-down)

Dimensions

ø230 × 200 (D) mm

Weight

3.7 kg (8.16 lbs)
