Key Specifications

Speaker Type

2-Way Coaxial (Flush Mount)

Rated Input

6 W (High Impedance)

LF Driver

12 cm (5") Cone-type

HF Driver

Balanced Dome-type Tweeter

Sensitivity

89 dB (1 W, 1 m)

Tapping & Impedance

100 V Line

6W / 3W / 1W / 0.5W

70 V Line

6W / 3W / 1.5W / 0.5W / 0.25W

Low Impedance

8 Ω (18W Program)

Performance & Physical

Frequency Response

80 Hz – 20,000 Hz (-10 dB)

Mounting Hole

ø200 mm (7.87")

Input Terminal

Push-in Connector (2-branch bridge type)

Dimensions

ø230 × 154 (D) mm

Weight

1.5 kg (3.3 lbs)
