Key Specifications

Input Section

Microphone Inputs (4)

• Connectors: 4 x XLR Inputs
• Gain Range: 0 to -50 dB
• Phantom Power: +48 V
• Low Cut Filters: 80 Hz
• Impedance: 14 Kilohms

Line Inputs

• 1/4" Inputs: 10 (4 x Stereo Pairs, 2 Mono)
• RCA Inputs: 4 (2 x Stereo Pair)
• Gain Selection: 20 dB to -30 dB
• Impedance: 21 kΩ (Line) / 15 kΩ (Stereo)

Output Section

Signal Outputs

• Main Outputs: 2 x XLR, 2 x 1/4"
• Monitor Outputs: 2 x 1/4" CTL Room Out
• Auxiliary/FX: 1 x 1/4" Auxiliary Output
• Headphones: 1 x 1/4" (150 Ohms)
• Output Level: 28 dBu

System Processing & USB

Audio Processing

• Compressors: Single-Control (CH 1 and 2)
• EQ High: ±15 dB @ 10 kHz (Shelving)
• EQ Mid: ±15 dB @ 1250 Hz (Bell)
• EQ Low: ±15 dB @ 100 Hz (Shelving)

Digital Connectivity

• USB Audio: Type-B, 2-Channel I/O
• Sample Rates: 44.1 or 48 kHz
• Footswitch: 1 x 1/4" Input

Physical & Electrical

Dimensions & Weight

• Size (WxHxD): 11.6 x 3.2 x 10.8" / 29.4 x 8.2 x 27.5 cm
• Weight: 6.2 lb / 2.8 kg
• Material: Metal Case

Power Requirements

• Voltage: 100 to 240 VAC (External PSU)
• Consumption: 18 W

Packaging Info

• Package Weight: 8.395 lb
• Box Dimensions: 16.8 x 13.8 x 5.4"
