Key Specifications

Mixing Architecture

• Mix Routing: Main Mix / FX Bus / Bus Subgroup
• Level Adjustment: 8 x Channel Faders
• Monitoring: 2 x 10-Segment LED Meters

Processing & Performance

• EQ (Mono): 3-Band EQ
• EQ (Stereo): 2-Band EQ
• THD+N: < 0.02% @ +20 dB Gain

Connectivity

Analog Inputs

• Mic: 4 x XLR 3-Pin (+48V Phantom)
• Mono Line: 2 x 1/4" Input
• Stereo Line: 8 x 1/4" (4 Stereo Pairs)
• Auxiliary: 2 x Stereo RCA Input
• Footswitch: 1 x 1/4" Input

Analog Outputs

• Main: 2 x XLR 3-Pin, 2 x 1/4" Output
• Control Room: 2 x 1/4" Output
• Aux/Phones: 1 x 1/4" Aux Out, 1 x 1/4" TRS Headphone

Digital I/O

• USB: 1 x USB-B (2-in / 2-out Capacity)
• Compatibility: Windows / macOS

Physical & Power

Dimensions & Weight

• Size: 11.6 x 3.2 x 10.8" / 29.4 x 8.2 x 27.5 cm
• Weight: 6.2 lb / 2.8 kg
• Rack Mountable: No

Electrical Specifications

• AC Power: 100 to 240 VAC, 50/60 Hz
• Mic Impedance: 14 Kilohms
• Line Impedance: 21 Kilohms

Packaging Info

• Package Weight: 13.3 lb
• Box Dimensions: 17.3 x 16.9 x 6.6"
