Key Specifications

Mixing Architecture

• Mix Routing: Main Mix / FX Bus / Bus/Subgroup
• Level Adjustment: 8 x Channel Faders
• Monitoring: 2 x 10-Segment LED Master Meters

Performance

• Frequency Response: 20 Hz to 20 kHz
• THD+N: < 0.02% @ +20 dB Gain (A-Weighted)
• Phantom Power: +48 V (Global)

Input / Output Section

Analog Inputs

• Mic: 4 x XLR 3-Pin Balanced
• Mono Line: 2 x 1/4" Input
• Stereo Line: 8 x 1/4" (4 Stereo Pairs)
• Auxiliary: 2 x Stereo RCA Input
• Other: 1 x 1/4" Footswitch Input

Analog Outputs

• Main Out: 2 x XLR 3-Pin, 2 x 1/4"
• Control Room: 2 x 1/4" Output
• Aux/Phones: 1 x 1/4" Aux Out, 1 x 1/4" TRS Headphone

Processing & Digital

Equalization

• Mono Channels: 3-Band EQ
• Stereo Channels: 2-Band EQ

USB Interface

• Connection: 1 x USB-B (Stereo In/Out)
• Capability: 2x Input / 2x Output Recording/Playback
• Compatibility: Windows / macOS

Physical Specifications

Dimensions & Weight

• Size: 11.6 x 3.2 x 10.8" / 29.4 x 8.2 x 27.5 cm
• Weight: 6.2 lb / 2.8 kg
• Rack Mountable: No

Electrical

• Power: 100 to 240 VAC, 50 / 60 Hz
• Headphone Impedance: 150 Ohms
