Key Specifications

Frequency Response

20 Hz - 20 kHz

THD+N (20dB gain, 0dBu out)

<0,02% A-Weighted

Dynamic Range

> 85dB

Input Specifications

Total Channels

6

Mic Inputs (x2)

Gain: 0 to -50 dB | Imp: 14 kohm

Mic Input Noise / Low Cut

-124 dBu A-Weighted / 80 Hz

Phantom Power (+48V)

Yes

Mono Line Inputs (x2)

Gain: 20 to -30 dB | Imp: 21 kohm

Stereo Line Inputs (x2)

Gain: 20 to -30 dB | Imp: 15 kohm

Input Connectors

XLR, Jack, RCA

Output Specifications

Main MIX / FX Send / AUX

1 / 1 / 1

Phones Output

1 (150 ohm impedance)

Output Connectors

XLR, Jack

Max Output Level (Main/Aux)

28 dBu

Signal Processing & Features

EQ Configuration

2 Shelving / 1 Generic

EQ High / Mid / Low

10 kHz (±15dB) / 1.25 kHz (±15dB) / 100 Hz (±15dB)

Auxiliary / Internal Effects

1 FX POST / 1 Send Effect

Footswitch Support

Yes

Electrical & Physical

Power Supply / Voltage

External / 100 V - 240 V

Max Power Consumption

12 W

Cabinet Material / Color

Metal / Black

Dimensions (H x W x D)

79 x 210 x 255 mm / 3.11 x 8.27 x 10.04"

Net Weight

1.8 kg / 3.97 lbs

Shipping Information

Package Weight

2.75 kg / 6.06 lbs

Package Dimensions

122 x 378 x 260 mm / 4.8 x 14.88 x 10.24"
