Key Specifications

System Type

3" 2-Way Passive Line Array Module

Power Capacity

40W (Continuous) / 80W (Program)

Nominal Impedance

8 Ω

Sensitivity (1W/1M)

90 dB

Audio Performance

Frequency Response

100 Hz – 20 kHz (-10dB)

Maximum SPL @ 1m

106 dB Max

Dispersion (-6dB)

100° Horizontal / 30° Vertical

Crossover Frequency

2.5 kHz

Transducers & Hardware

LF Drivers

2 x 3" Woofer (0.75" Voice Coil)

HF Drivers

3 x Ø13mm Neodymium Tweeters

Rigging System

Adjustable Splay (0° to 12° in 1.5° increments)

Physical Specs

Enclosure Material

Polypropylene (with Steel Grille)

Dimensions (WxHxD)

265 x 124 x 195 mm

Net Weight

3.2 kg (7.05 lbs)
